Monitor Audio – Creator Series – W2M-CP In-Wall Speaker
The W2M-CP medium-sized Tier 2 in-wall loudspeaker is a three-way model designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement.
As a Controlled Performance (CP) model, it is fitted with a fully sealed back box that reduces the sound from the back of the cabinet by around 30 dB. This range guarantees excellent audio quality and versatility for a superior level of sound isolation between rooms and floors.
Unfortunately, this product is temporarily out of stock. We are awaiting information regarding the availability of this product.
Please contact us for alternatives and assistance.
Any Questions?
Our technical team is on hand to solve any problems or help you find the ideal solution.
Description
The W2M-CP medium-sized Tier 2 in-wall loudspeaker is a three-way model featuring two RST II (rigid surface technology) bass drivers, an RST II mid-range driver, and a C-CAM (Ceramic-Coated Aluminium/Magnesium) tweeter. Its fully sealed back box delivers consistency of performance, no matter where it is used.
This medium-sized Tier 2 in-wall loudspeaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. With the combination of two RST II bass drivers, an RST II mid-range driver, and a C-CAM tweeter, this loudspeaker produces a clear and lifelike, high-fidelity sound of the quality you’d expect from any Monitor Audio passive box loudspeaker.
As a Controlled Performance (CP) model, it is fitted with a fully sealed back box that provides an ideal air load for the drivers, optimising mid-range and bass performance while maintaining sonic consistency regardless of interior wall construction. These rigid, mineral-filled enclosures reduce the sound from the back of the cabinet by around 30 dB. This range guarantees excellent audio quality and versatility for a superior level of sound isolation between rooms and floors.
It has a cut-out dimension of 527 x 198 mm and a revolutionary Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable, and strong installation and fitting.
Key Features:
- Ideal for installations where pristine acoustic performance is required
- Filled back box
- Three-way design
- 1 x 1″ C-CAM tweeter with UD Waveguide II for lifelike sound
- 1 x 3″ RST II mid-range driver
- 2 x 5″ RST II bass drivers
- Quik-Link speaker cable connector for quicker installation
- Tri-Grip II for easy and secure fitment
What’s Included:
1 x W2M-CP In-Wall Speaker
1 x Quick Start Guide
1 x Cut-out Template
1 x Quik-Link Connector
1 x Safety Instructions
Product Specifications
Physical and Performance Attributes | |
|---|---|
| Dimensions (L x W x H) | 560 × 231 × 102 mm |
Misc Product Attributes | |
SpecificationsSystem Format 3-Way Channels 1 Frequency Response, Installed (-6dB) 60Hz – 35kHz Nominal Impedance 6 Ohm Minimum Impedance (20Hz to 20kHz) 4.8 Ohm @ 1kHz (4.3 Ohm @ 15kHz) Sensitivity (2.83Vrms@1m, Installed) 87dB Maximum Peak SPL* (single speaker @ 1m Z-Weighted) 118dB Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor) 100W Recommended Amplifier Power (RMS into 8 Ohm, Music Signal) 40 – 150W Drive Unit Complement 2 x 5″ (127mm) RST II bass driver 1 x 3″ (76mm) RST II midrange driver 1 x 1″ (25mm) C-CAM tweeter Crossover Frequency LF/HF: 550kHz MF/HF: 3kHz Bass Alignment Sealed Mounting Depth 97mm (3-13/16″) Cut-out L x W 527 x 198mm (20-3/4″ x 7-13/16″) External Dimensions (Including Grille (H x W x D)) 560x 231 x 102mm (22-1/16 x 9-1/8 x 4-1/64″) Weight (each) 4.4kg (9lb 11oz) Pre-Construction Bracket WM-B Cabinet Finish Matte Black & Orange & Bronze Sold As Single Unit Corner Switch On/Off HF Switch -/0/+ Warranty Lifetime
| |
