Monitor Audio – Creator Series – W2M In-Wall Speaker
The W2M medium-sized Tier 2 in-wall loudspeaker is a three-way model designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement.
Please contact us for pricing and purchase enquiries.
Any Questions?
Our technical team is on hand to solve any problems or help you find the ideal solution.
Description
The W2M medium-sized Tier 2 in-wall loudspeaker is a three-way model featuring two RST II (rigid surface technology) bass drivers, an RST II mid-range driver, and a C-CAM (Ceramic-Coated Aluminium/Magnesium) tweeter.
This medium-sized Tier 2 in-wall loudspeaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. It is a three-way model which delivers the combination of clear and lifelike high-fidelity sound of the quality you’d expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 527 x 198 mm, utilises the revolutionary Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable, and strong installation and fitting.
Key Features:
- Ideal for installations where pristine acoustic performance is required
- Three-way design
- 1 x 1″ C-CAM tweeter with UD Waveguide II for lifelike sound
- 1 x 3″ RST II mid-range driver
- 2 x 5″ RST II bass drivers
- Quik-Link speaker cable connector for quicker installation
- Tri-Grip II for easy and secure fitment
What’s Included:
1 x W2M In-Wall Speaker
1 x Quick Start Guide
1 x Cutout Template
1 x Quik-Link Connector
1 x Safety Instructions
Product Specifications
Physical and Performance Attributes | |
---|---|
Weight | 3.9 KG |
Dimensions (L x W x H) | 560 × 231 × 90 mm |
Misc Product Attributes | |
SpecificationsSystem Format 3-Way Channels 1 Frequency Response, Installed (-6dB) 40Hz – 35kHz Nominal Impedance 6 Ohm Minimum Impedance (20Hz to 20kHz) 4.8 Ohm @ 1kHz (4.8 Ohm @ 15kHz) Sensitivity (2.83Vrms@1m, Installed) 87dB Maximum Peak SPL* (single speaker @ 1m Z-Weighted) 116dB Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor) 120W Recommended Amplifier Power (RMS into 8 Ohm, Music Signal) 45 – 180W Drive Unit Complement 2 x 5″ (127mm) RST II bass driver 1 x 3″ (76mm) RST II midrange driver 1 x 1″ (25mm) C-CAM tweeter Crossover Frequency LF/HF: 650kHz MF/HF: 3kHz Mounting Depth 85mm (3-3/8″) Cut-out L x W 527 x 198mm (20-3/4″ x 7-13/16″) External Dimensions (Including Grille (H x W x D)) 560x 231 x 90mm (22-1/16 x 9-1/8 x 3-9/16″) Weight (each) 3.9kg (8lb 9oz) Pre-Construction Bracket WM-B Cabinet Finish Matte Black & Orange & Bronze Sold As Single Unit Corner Switch On/Off HF Switch -/0/+ Warranty Lifetime |
