Monitor Audio – W165 In-Wall Speakers

Incorporating a 6 1/2″ MMP II bass driver with Monitor Audio’s signature C-CAM Gold Dome tweeter to provide high performance sound, ease-of-drive, and wide frequency response and dispersion.

£200.00 inc VAT

Free Shipping for Mainland UK orders ** (excluding Scottish Highlands)

SKU: SCW165 Category: Tag:

EAN / Barcode: 05060028972401

product-page-callout-v1-_installer

Need an Installer?

Fill out our enquiry form and we’ll put you in contact with a trusted installer in your area.

Installer Enquiry Form

    How would you prefer to be contacted?

    What areas of Home Automation are you interested in?

    product-page-callout-v1-_support

    Any Questions?

    Our technical team is on hand to solve any problems or help you find the ideal solution.

      Description

      Incorporating a 6 1/2″ MMP II bass driver with Monitor Audio’s signature C-CAM Gold Dome tweeter to provide high performance sound, ease-of-drive, and wide frequency response and dispersion.

      Optimum imaging and set-up are established via a pivoting tweeter and high-frequency (+3 dB / 0 dB /-3 dB) level adjustment.

      Technical Specs

      • Frequency Response: 60 Hz – 25 kHz
      • Nominal Impedance: 6 ohms
      • Sensitivity (1W@1M): 88.5 dB
      • Maximum SPL: 107.4 dBA
      • Power Handling (RMS): 65 W
      • Recommended Amplifier Requirements: 20 – 65 W
      • Drive Unit Complement: 6 1/2MMP II cone bass driver & 1″ C-CAM pivoting Gold Dome tweeter
      • Adjustment Controls: HF Level Switch (+3 dB / 0 dB / -3 dB)
      • Overall Diameter (Including Grille): 370 x 250 mm (149/16 x 913/16“)
      • Overall Depth (Including Grille): 96 mm (33/4“)
      • Mounting Depth: 92 mm (35/8“)
      • Cut-Out Hole Diameter: 332 x 213 mm (131/16 x 83/8“)
      • Fixing Type: 6 position Tri-Grip dog fixings

      Informational Video

      In-Wall Speaker | Installation Guide

      Product Specifications

      Physical and Performance Attributes

      Weight2.21 KG
