Shelly Qubino Wave Pro 3

The Shelly Qubino Wave Pro 3 is a three‑channel smart switch rated at 16A per channel, with dry contacts for versatile voltage use.

£99.49 inc VAT

SKU: QUBINO-WAVE-PRO-3 Category:
product-page-callout-v2-_support-full-width

Any Questions?

Our technical team is on hand to solve any problems or help you find the ideal solution.

Contact Us

Description

The Shelly Qubino Wave Pro 3 is a three‑phase, three‑channel relay capable of handling up to 48 A, with two outputs rated at 16 A each. Designed for DIN‑rail installation inside a junction box, it provides professional-level control of existing electrical systems, including advanced smart lighting setups and efficient climate management. By automatically switching off non‑essential, high‑consumption devices, the Wave Pro 3 can also help reduce operational costs in commercial environments.

Operating on the Z‑Wave protocol, the Shelly Qubino Wave Pro 3 works seamlessly with any Z‑Wave gateway, making it a straightforward addition to existing smart home or office ecosystems. It features a robust set of security protocols to safeguard your network and supports direct device‑to‑device communication, enabling automated actions even without a central hub.

Please note: A Z‑Wave gateway (smart hub) is required for configuration and is sold separately.

Key Features:

  • Z-Wave operated
  • Dry contact support
  • 3 channel switch, 16A each
  • Two-directional roller control
  • Smart schedules
  • Smart scenes
  • Automatic sunrise/sunset schedules
  • Automatic on/off timer
  • Enhanced security (MQTT, WSS and TLS certificate support)
  • DIN rail mountable

What’s Included:

  • 1 x QUBINO-WAVE-PRO-3
  • 1 x Installation Guide

Manuals & Data sheets:

Product Specifications

Physical and Performance Attributes

Weight150 grams
Dimensions (L x W x H)96 × 53 × 59 mm

Misc Product Attributes

Specification Details
Power supply 110 – 240 V ~ 50/60 Hz
Power consumption < 0.3W
Power measurement [W] No
Max. switching voltage AC 240 V
Max. switching current AC 16 A per channel, 48 A total
Max. switching voltage DC 30 V
Max. switching current DC 16 A per channel, 48 A total
Overheating protection Yes
Distance Up to 40 m indoors (131 ft.) (depends on local conditions)
Z-Wave® repeater Yes
CPU Z-Wave® S800
Z-Wave® frequency bands 868.4 MHz
Max RF power < 25 mW
Size (H × W × D) 96×53×59 ± 0.5 mm / 3.78×2.01×2.32 ± 0.02 in
Weight 150 g / 5.29 oz
Mounting DIN rail
Screw terminals max. torque 0.4 Nm / 3.54 lbin
Conductor cross section 0.5 to 2.5 mm² / 20 to 14 AWG (green connector)
Conductor stripped length 6 to 7 mm / 0.24 to 0.28 in (green connector)
Shell material Plastic
Color Black
Ambient temperature -20°C to 40°C / -5°F to 105°F
Humidity 30% to 70% RH
Max. altitude 2000 m / 6562 ft.
