Monitor Audio – Creator Series – C2M-CP In-Ceiling Speaker

The C2M-CP is a medium-sized Tier 2 in-ceiling loudspeaker, featuring an RST II (rigid surface technology) mid-bass driver and C-CAM (Ceramic-Coated Aluminium/Magnesium) tweeter. Its fully sealed back box delivers consistency of performance, no matter where it is used. These rigid, mineral-filled enclosures reduce the sound from the back of the cabinet by around 30 dB, guaranteeing excellent audio quality and versatility and offering superior sound isolation between rooms and floors.

Please contact us for pricing and purchase enquiries.

SKU: C2M-CP Categories: , Tags: ,
product-page-callout-v2-_support-full-width

Any Questions?

Our technical team is on hand to solve any problems or help you find the ideal solution.

Description

The C2M-CP is a medium-sized Tier 2 in-ceiling loudspeaker, featuring an RST II (rigid surface technology) mid-bass driver and C-CAM (Ceramic-Coated Aluminium/Magnesium) tweeter. Its fully sealed back box delivers consistency of performance, no matter where it is used. It has a cutout dimension of 212 mm and a revolutionary Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable, and strong installation and fitting.

This medium-sized Tier 2 in-ceiling loudspeaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. The performance benefit of having both an RST II mid-bass driver and C-CAM tweeter within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear, lifelike, high-fidelity sound—of the quality you’d expect from any Monitor Audio passive box loudspeaker.

As a Controlled Performance (CP) model, it is fitted with a fully sealed back box that provides an ideal air load for the drivers, optimising mid-range and bass performance while maintaining sound consistency regardless of interior wall construction. These rigid, mineral-filled enclosures reduce the sound from the back of the cabinet by around 30 dB. This range guarantees excellent audio quality and versatility and offers superior sound isolation between rooms and floors.

Key Features:

  • Ideal for installations where pristine acoustic performance is required
  • Fitted back box
  • Two-way design
  • 1 x 1″ C-CAM tweeter with UD Waveguide II for lifelike sound
  • 1 x 7″ RST II mid-bass driver
  • Quik-Link speaker cable connector for quicker installation
  • Tri-Grip II for easy and secure fitment
  • Optional Black Grille in round and square designs

What’s Included:

1 x C2M-CP In-ceiling speaker

1 x White Magnetic Grille

1 x Quick Start Guide

1 x Cutout Template

1 x Quik-Link Connector

1 x Safety Instructions

Product Specifications

Physical and Performance Attributes

Weight2.6 KG
Dimensions (L x W x H)242 × 242 × 181.5 mm

Misc Product Attributes

Specifications

System Format

2-Way

Channels

1

Frequency Response, Installed (-6dB)

70Hz – 35kHz

Nominal Impedance

8 Ohm

Minimum Impedance (20Hz to 20kHz)

6.4 Ohm @ 15kHz

Sensitivity (2.83Vrms@1m, Installed)

87dB

Maximum Peak SPL* (single speaker @ 1m Z-Weighted)

116dB

Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)

65W

Recommended Amplifier Power (RMS into 8 Ohm, Music Signal)

35 – 130W

Drive Unit Complement

1 x 7″ (178mm) RST II mid-bass driver

1 x 1″ (25mm) C-CAM Tweeter

Crossover Frequency

LF/HF: 2.5kHz

Bass Alignment

Sealed

Mounting Depth

177.5mm (6-63/64″)

Cut-out Hole Diameter

212mm (8-3/8″)

External Dimensions (Including Grille (H x W x D))

242x 242 x 181.5mm (9-1/2 x 9-1/2 x 4-4/16″)

Weight (each)

2.6kg (5lb 11oz)

Pre-Construction Bracket

CM-B

Cabinet Finish

Matte Black & Orange & Bronze

Sold As

Single Unit with CM-Round Grille (white)

Corner Switch

On/Off

HF Switch

-/0/+

Warranty

Lifetime
