Monitor Audio – Creator Series – C2S In-Ceiling Speaker
The C2S In-Ceiling Speaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. It is a two-way model featuring an RST II (rigid surface technology) mid-bass driver and C-CAM (Ceramic-Coated Aluminium/Magnesium) tweeter. The performance benefit of having both within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear, lifelike, high-fidelity sound—of the quality you’d expect from any Monitor Audio passive box loudspeaker.
Please contact us for pricing and purchase enquiries.
Any Questions?
Our technical team is on hand to solve any problems or help you find the ideal solution.
Description
The C2S is a small sized Tier 2 in-ceiling, two-way model loudspeaker. It has a cut-out dimension of 171 mm and utilises a revolutionary Quik-Link speaker cable connector and Tri-Grip II technology for quick, simple, reliable, and strong installation and fitting.
This loudspeaker is designed to deliver pristine, engaging acoustics where high-performance sound is a key requirement. It is a two-way model featuring an RST II (rigid surface technology) mid-bass driver and C-CAM (Ceramic-Coated Aluminium/Magnesium) tweeter. The performance benefit of having both within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear, lifelike, high-fidelity sound—of the quality you’d expect from any Monitor Audio passive box loudspeaker.
Key Features:
- Ideal for installations where pristine acoustic performance is required
- Two-way design
- 1 x 1″ C-CAM tweeter with UD (Uniform Dispersion) Waveguide I 1 x 5″ RST II mid-bass driver
- Quik-Link speaker cable connector for quicker installation
- Tri-Grip II for easy and secure fitment
- Optional Black Grille in round and square designs
What’s Included:
1 x C2S In-ceiling speaker
1 x White Magnetic Grille
1 x Quick Start Guide
1 x Cutout Template
1 x Quik-Link Connector
1 x Safety Instructions
Product Specifications
Physical and Performance Attributes | |
|---|---|
| Weight | 1.5 KG |
| Dimensions (L x W x H) | 201 × 201 × 103 mm |
Misc Product Attributes | |
SpecificationsSystem Format 2-Way Channels 1 Frequency Response, Installed (-6dB) 40Hz – 30kHz Nominal Impedance 8 Ohm Minimum Impedance (20Hz to 20kHz) 6.8 Ohm @ 150Hz Sensitivity (2.83Vrms@1m, Installed) 84dB Maximum Peak SPL* (single speaker @ 1m Z-Weighted) 111dB Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor) 65W Recommended Amplifier Power (RMS into 8 Ohm, Music Signal) 35 – 130W Drive Unit Complement 1 x 5″ (127mm) RST II mid-bass driver 1 x 1″ (25mm) C-CAM Tweeter Crossover Frequency LF/HF: 2.5kHz Mounting Depth 99mm (3-7/8″) Cut-out Hole Diameter 171mm (6-3/4″) External Dimensions (Including Grille (H x W x D)) 201 x 201 x 103mm (7-15/16 x 7-15/16 x 4-4/16″) Weight (each) 1.5kg (3lb 5oz) Pre-Construction Bracket CS-B Cabinet Finish Matte Black & Orange & Bronze Sold As Single Unit with CS-Round Grille (white) Corner Switch On/Off HF Switch -/0/+ Warranty Lifetime
| |
