Monitor Audio – Creator Series – C3L-CP In-Ceiling Speaker
The C3L-CP In-Ceiling Loudspeaker really is the last word in installed performance, featuring an RDT III bass driver, an IDC II midrange driver, and an IDC II tweeter with UD Waveguide II. This combination ensures levels of acoustic transparency and detail found in Monitor Audio’s premium loudspeaker ranges.
Please contact us for pricing and purchase enquiries.
Any Questions?
Our technical team is on hand to solve any problems or help you find the ideal solution.
Description
The C3l-CP Tier 3 in-ceiling loudspeaker is a three-way model featuring an RDT III (Rigid Diaphragm Technology) bass driver, IDC (Inverted Dual Concentric) II midrange driver, and IDC II tweeter with UD Waveguide II. Its fully sealed back box delivers consistently high performance, no matter where it is used.
This high-performance, large Tier 3 in-ceiling loudspeaker is designed to deliver top-of-the-range, crisp acoustics where pristine sound quality is desired. It is a three-way model featuring the very latest acoustic technologies from Monitor Audio.
This really is the last word in installed performance, featuring an RDT III bass driver, an IDC II midrange driver, and an IDC II tweeter with UD Waveguide II. This combination ensures levels of acoustic transparency and detail found in Monitor Audio’s premium loudspeaker ranges, where much of this acoustic technology was developed.
As a Controlled Performance (CP) model, it is fitted with a fully sealed back box that provides an ideal air load for the drivers, optimising mid-range and bass performance while maintaining sonic consistency regardless of interior wall construction. These rigid, mineral-filled enclosures reduce the sound from the back of the cabinet by around 30 dB. This range guarantees excellent audio quality and versatility, for a superior level of sound isolation between rooms and floors.
It has a cut-out dimension of 248 mm and revolutionary Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable, and strong installation and fitting.
Key features:
- Ideal for installations where high-performance acoustics are desired
- Fitted back box
- Three-way design
- Mid-frequency ‘mid-pod array’
- 1 x 1″ IDC II tweeter with UD Waveguide II for lifelike sound
- 1 x 9″ RDT III bass driver
- 1 x 4″ IDC II midrange driver
- Quik-Link speaker cable connector for quicker installation
- Tri-Grip II for easy and secure fitment
- An optional square grille can be used with this model
What’s Included:
1 x C3L-CP In-ceiling speaker
1 x White Magnetic Grille
1 x Quick Start Guide
1 x Cutout Template
1 x Quik-Link Connector
1 x Safety Instructions
Product Specifications
Physical and Performance Attributes | |
|---|---|
| Weight | 5.7 KG |
| Dimensions (L x W x H) | 278 × 278 × 181 mm |
Misc Product Attributes | |
SpecificationsSystem Format 3-Way Channels 1 Frequency Response, Installed (-6dB) 80Hz – 35kHz Nominal Impedance 6 Ohm Minimum Impedance (20Hz to 20kHz) 4.9 Ohm @ 2kHz Sensitivity (2.83Vrms@1m, Installed) 89dB Maximum Peak SPL* (single speaker @ 1m Z-Weighted) 122dB Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor) 120W Recommended Amplifier Power (RMS into 8 Ohm, Music Signal) 45 – 180W Drive Unit Complement 1 x 9″ (229mm) RDT III bass driver 1 x 4″ (102mm) IDC II midrange driver 1 x 1″ (25mm) IDC II tweeter Crossover Frequency LF/MF: 700Hz MF/HF: 3.5kHz Bass Alignment: Sealed Mounting Depth 177.5mm (6-63/64″) Cut-out Hole Diameter 248mm (9-3/4″) External Dimensions (Including Grille (H x W x D)) 278x 278 x 181mm (10-15/16 x 10-15/16 x 7-1/8″) Weight (each) 5.7kg (12lb 10oz) Pre-Construction Bracket CL-B Cabinet Finish Matte Black & Orange & Green Sold As Single Unit with CL-Round Grille (white) Corner Switch On/Off HF Switch -/0/+ MF Switch -/0/+ Warranty Lifetime | |
