Monitor Audio – Creator Series – C3L In-Ceiling Speaker

The C3L is a high-performance, large Tier 3 in-ceiling loudspeaker, designed to deliver pristine, engaging acoustics. It is a three-way model featuring the very latest acoustic technologies from Monitor Audio.

Please contact us for pricing and purchase enquiries.

SKU: C3L Categories: , Tags: ,
product-page-callout-v2-_support-full-width

Any Questions?

Our technical team is on hand to solve any problems or help you find the ideal solution.

Description

The C3L Tier 3 in-ceiling loudspeaker is a three-way model featuring an RDT III (Rigid Diaphragm Technology) bass driver, IDC II (Inverted Dual Concentric) midrange driver, and IDC II tweeter with UD Waveguide II.

This high-performance, large Tier 3 in-ceiling loudspeaker is designed to deliver crystal clear, engaging acoustics where pristine sound quality is desired. It is a three-way model featuring the very latest acoustic technologies from Monitor Audio.

The C3L really is the last word in installed performance, featuring an RDT III bass driver, IDC II midrange driver, and IDC II tweeter with UD Waveguide II. This high-end combination ensures levels of acoustic transparency and detail found in Monitor Audio’s premium loudspeaker ranges, where much of this acoustic technology was developed. It has a cutout diameter of 248 mm and uses the Quik-Link speaker cable connector, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable, and strong fitment.

Key Features:

  • Ideal for installations where high-performance acoustics are desired
  • Three-way design
  • Mid-frequency ‘mid-pod array’
  • 1 x 1″ IDC II tweeter with UD Waveguide II for lifelike sound
  • 1 x 9″ RDT III bass driver
  • 1 x 4″ IDC II midrange driver
  • Quik-Link speaker cable connector for quicker installation
  • Tri-Grip II for easy and secure fitment
  • An optional square or premium grille can be used with this model

What’s Included:

1 x C3L In-ceiling speaker

1 x White Magnetic Grille

1 x Quick Start Guide

1 x Cutout Template

1 x Quik-Link Connector

1 x Safety Instructions

Product Specifications

Physical and Performance Attributes

Weight5 KG
Dimensions (L x W x H)278 × 278 × 161 mm

Misc Product Attributes

Specifications

System Format

3-Way

Channels

1

Frequency Response, Installed (-6dB)

45Hz – 35kHz

Nominal Impedance

6 Ohm

Minimum Impedance (20Hz to 20kHz)

4.8 Ohm @ 2kHz

Sensitivity (2.83Vrms@1m, Installed)

89dB

Maximum Peak SPL* (single speaker @ 1m Z-Weighted)

119dB

Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)

150W

Recommended Amplifier Power (RMS into 8 Ohm, Music Signal)

60 – 225W

Drive Unit Complement

1 x 9″ (229mm) RDT III bass driver

1 x 4″ (102mm) IDC II midrange driver

1 x 1″ (25mm) IDC II tweeter

Crossover Frequency

LF/MF: 700Hz

MF/HF: 3.5kHz

Mounting Depth

157mm (6-3/16″)

Cut-out Hole Diameter

248mm (9-3/4″)

External Dimensions (Including Grille (H x W x D))

278x 278 x 161mm (10-15/16 x 10-15/16 x 6-5/16″)

Weight (each)

5kg (11lb)

Pre-Construction Bracket

CL-B

Cabinet Finish

Matte Black & Orange & Green

Sold As

Single Unit with CL-Round Grille (white)

Corner Switch

On/Off

HF Switch

-/0/+

MF Switch

-/0/+

Warranty

Lifetime
