Somfy Telis 16 RTS Pure
The Telis 16 remote is ideal for controlling up to 16 different Somfy RTS products individually or as a group, such as your lighting, powered blinds or roller shutters.
Please contact us for pricing and purchase enquiries.
Any Questions?
Our technical team is on hand to solve any problems or help you find the ideal solution.
Description
Features:
The easy to program Telis 16 handset lets you operate up to 16 different Somfy RTS products, either individually or as a group. The LCD display shows you which channel is currently selected, while the channel selector button makes it easy to navigate between them. The channel names and icons can even be adapted to make controlling your automated products even easier.
This contemporary styled remote makes modern day living so simple, with wireless one touch control allowing you to open or close your Somfy products from the comfort of your chair. The three buttons include raise, lower and stop functionalities, along with a ‘my’ button. This means you can program and instantly recall your preferred position.
Controls up to 16 Somfy RTS powered blinds or other RTS enabled products, e.g. electric curtain tracks or lighting modules.
Includes raise, lower and stop functions, and programmable ‘my’ button.
LCD display makes it easy to program and navigate between channels.
Assign each channel a name, icon and/or number.
Create groups to simultaneously operate multiple RTS products in the same zone.
Battery powered with no wiring required.
Supplied with a mounting bracket for easy storage.
Comes with a comprehensive 2 year warranty.
What’s included:
1x Telis 16 Pure-16 channel remote control
1x Battery
1x Wallmount
Alternative Model Numbers:
181102050
Frequently Asked Questions
How do I program or rename channels?
Use the on-screen interface: select a channel, hold the set button until “SET” appears, then assign icons or text using navigation buttons.
How do I assign a device to a channel?
Press and hold the receiver’s PROG button until it jogs. On the Telis 16, select the channel and press the button to pair. The motor will acknowledge with a jog. Repeat for other channels as needed
What does the “My” button do?
“My” stops movement and recalls your saved favorite position when pressed. Great for customized comfort positioning.
Product Specifications
Physical and Performance Attributes | |
|---|---|
| Weight | 750 grams |
| Dimensions (L x W x H) | 145 × 47 × 18 mm |
| Protection Rating (IP) | 30 |
| Vandal Resistant? | No |
| Mounting Type | Optional Surface Mount Housing Available |
| Operating Temperature | 0°C to +45°C |
Electronics Attributes | |
| Battery Type | AAA / LR03 (1.5v) |
| Number of Batteries | 1 |
Remote Control, Radio & Receiver Attributes | |
| Radio Frequency | 433.42 MHz |
| Range | 200m in open field or 20m through 2 reinforced concrete walls |
Misc Product Attributes | |
Compatible with the Somfy RTS range of motors and sensors. For indoor use Measurements: 145 x 47 x 18 mm Weight : 0.75 Kg Battery Type: LR03 AAA Battery Voltage: 1.5 V Protection Index: IP 30 Radio Frequency: 433.42 MHz Radio Range: 200m in open field or 20m through 2 reinforced concrete walls Channels: 16 Colour / Finish: neutral white Installation: Supplied with a mounting bracket (for wall mount option). Information: Shock-proof Working temperature : 0 to + 45 °C Warranty: 5 years | |
