TP-Link Archer A7 – AC1750 Wireless Dual Band Gigabit WiFi Router

AC1750 Wireless Dual Band Gigabit WiFi Router

Unfortunately, this product is temporarily out of stock. We are awaiting information regarding the availability of this product.

Please contact us for alternatives and assistance.

SKU: ARCHER A7 Category: Tags: , , , ,

EAN / Barcode: 6935364083861


TP-Link Archer A7 – AC1750 Wireless Dual Band Gigabit WiFi Router is compatible with the following systems:
Wi-Fi Compatible Device


Any Questions?

Our technical team is on hand to solve any problems or help you find the ideal solution.


AC1750 Wireless Dual Band Gigabit Router

Archer A7

The New Wi-Fi Standard for an Advanced Online Experience

The Archer A7 is a high-performance 802.11ac router with a long range. It outperforms several routers that cost twice as much. This enhanced Wi-Fi is intended for high-volume online activity and can help programmes run three times faster than the preceding 802.11n standard.

Concurrent Dual Band Connections for Lag-Free Work and Entertainment

The Archer A7 supports both the 2.4GHz and 5GHz bands, ensuring excellent wireless coverage. The 2.4GHz band can handle simple tasks like writing e-mails or browsing the internet, while the 5GHz band can handle bandwidth-intensive applications like online gaming or HD video streaming – all at the same time.

External Antennas with Dual Band Wi-Fi Greatly Expand Wireless Coverage

You can sustain outstanding speeds thanks to three external antennas and innovative connection technology. You can experience great wireless coverage and reliability in any section of your large house or workplace with antennas that serve both the 2.4GHz and 5GHz bands.


The crystal clean 5GHz band is ideal for HD streaming and gaming, creating a blazing-fast network.


The 2.4GHz band provide stable and strong Wi-Fi signal for everyday tasks, like browsing and surfing.

Versatile USB Connectivity

The Archer A7 has a USB 2.0 port, making it a genuinely versatile gateway. When you're not at home, share a hard drive full of media over your home network or an ftp server.

Full Gigabit Wired Connections for Ultrafast Data Transfer Speeds

Speeds can be up to 10 times quicker than regular Ethernet connections when using one Gigabit WAN port and four Gigabit LAN connectors. The Archer A7 is a powerful hub that can help you build a reliable and fast wired network.

Parental Controls

Parental Controls

Manage when and how connected devices can access the internet

IPv6 Supported

IPv6 Supported

Supports IPv6, the next generation of Internet protocol, helping you to future-proof your network.

Quality of Service

Quality of Service

Prioritizes devices or applications to give faster performance where you need it.


  • Supports 802.11ac standard - 3 times faster than wireless N speeds
  • Simultaneous 2.4GHz 450 Mbps and 5GHz 1300 Mbps connections for 1.75Gbps of total available bandwidth
  • USB Port - easily shares files & media with networked devices or remotely via FTP server
  • Guest Network Access - provides secure Wi-Fi access for guests sharing your home or office network
  • Easy setup and management with Tether App
  • Wi-Fi Router Archer A7
  • Power Adapter
  • RJ45 Ethernet Cable
  • Quick Installation Guide

Manuals & Datasheets

TP-Link Archer A7 AC1750 Wireless Dual Band Gigabit WiFi Router Quick Installation Guide
TP-Link Archer A7 AC1750 Wireless Dual Band Gigabit WiFi Router Datasheet
TP-Link Archer A7 AC1750 Wireless Dual Band Gigabit WiFi Router User Guide

  • Wi-Fi 5

    • IEEE 802.11ac/n/a 5 GHz
    • IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds
  • AC1750

    • 5 GHz: 1300 Mbps (802.11ac)
    • 2.4 GHz: 450 Mbps (802.11n)
Wifi Range
  • 3 Bedroom Houses

    • 3× Fixed High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas
WiFi Capacity
  • Medium

    • Dual Band
      • Allocate devices to different bands for optimal performance
Working Modes
  • Router Mode
  • Access Point Mode
  • Qualcomm CPU
Ethernet Ports
  • 1× Gigabit WAN Port
  • 4× Gigabit LAN Ports
USB Support
  • 1× USB 3.0 Port

  • Supported Partition Formats:
  • NTFS and FAT32

  • Supported Functions:
  • FTP Server
  • Media Server
  • Samba Server
  • Wi-Fi On/Off Button
  • Power On/Off Button
  • WPS/Reset Button
  • 12 V ⎓ 1.5 A
Wifi Encryption
  • WPA
  • WPA2
  • WPA/WPA2-Enterprise (802.1x)
Network Security
  • SPI Firewall
  • Access Control
  • IP & MAC Binding
  • Application Layer Gateway
Guest Network
  • 1 x 5GHz Guest Network
  • 1 x 2.4GHz Guest Network
  • IPv4, IPv6
  • OneMesh™ Supported

  • Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
  • Learn More
Parental Controls
  • URL Filtering
  • Time Controls
WAN Types
  • Dynamic IP, Static IP, PPPoE, PPTP, L2TP
Quality of Service
  • QoS by Device
Cloud Service
  • OTA Firmware Upgrade, TP-Link ID, DDNS
NAT Forwarding
  • Virtual Server, Port Forwarding, Port Triggering, DMZ, UPnP
  • IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN
  • Address Reservation, DCHP Client List, Server
  • TP-Link, NO-IP, DynDNS
  • 243 × 160.6 × 32.5 mm
Operating Temperature
  • 0°C - 40°C
Storage Temperature
  • -40°C - 70°C
Operating Humidity
  • 10%-90% non-condensing
Storage Humidity
  • 5%-90% non-condensing
System Requirements
  • Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

  • Cable or DSL Modem (if needed)

  • Subscription with an internet service provider (for internet access)
  • FCC, CE, RoHS
WiFi Transmission Power
  • CE:
    • <20dBm(2.4GHz)
    • <23dBm(5GHz)
  • FCC:
    • <30dBm

*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.

Manuals and Guides


Product Specifications

Physical and Performance Attributes

Weight590 grams
Dimensions (L x W x H)160.6 × 243 × 32.5 mm

243 × 160.6 × 32.5 mm

Operating Temperature0℃~40℃
Operating Humidity10%~90% non-condensing

Electronics Attributes

Power Supply12 V ⎓ 1.5 A
