Aqara Smoke Detector

Stay safe with the Aqara Smoke Detector. This smart device offers real-time smoke detection, 85dB siren alerts, and app notifications, with up to 10 years of battery life. It integrates with major smart home ecosystems like HomeKit, Alexa, and Google Home, and supports local automations even without an internet connection.

£44.99 inc VAT

Available on back-order

Free Shipping for Mainland UK orders over £15 incl. VAT ** (excluding Scottish Highlands)

Compatibility

Aqara Smoke Detector is compatible with the following systems:
Zigbee CompatibleWorks with Apple HomekitWorks with Siri ShortcutsWorks with AlexaWorks with the Google Assistant

SKU: SD-S01D Category: Tag:

EAN / Barcode: 6975833356898

Description

Aqara Smoke Detector

Detection and Protection at the First Sign of Smoke

Aqara Smoke Detector is a self-contained photoelectric smoke detection alarm. When smoke is detected to reach the configured threshold value, the detector will release a sound and light alarm signal and send a notice to the Aqara App via the hub immediately. The smoke detector integrates effortlessly with major ecosystems through Matter support and supports local automations, ensuring your safety measures whether you can connect to the internet or not.

Aqara Smoke Detector Features:

  • Alerts you via siren & via app: The Smoke Detector provides real-time smoke concentration monitoring, quickly issuing alarms when density exceeds the threshold to protect your home and family. Thanks to local automation, you can receive notifications via the Aqara Home app when danger occurs even without an internet connection.
  • Multi-Device Grouping*: With multiple device groups function, all connected smoke detectors will be trigger  if one detector alarms to ensure you and your family can hear it no matter how large your house is.
  • 10-Year Battery Life: The low-power technology of the Smoke Detector allows the battery to last up to ten years, eliminating the worries for users to frequently replace batteries.
  • Built in Siren of up to 85dB: The Smoke Detector is built in a powerful siren for up to 85dB and a blinking LED, ensuring you and your family are alerted to danger even if you’re in another room, sleeping, or listening to loud music.
  • Wide Compatibility: With Aqara Zigbee3.0 hubs***, Users can combine Smoke Detector with smart devices from different ecosystems to enhance the intelligence and interactivity of home devices, including HomeKit, Alexa, Google Home e.g.
  • Smart Home Automations: The Smoke Detector is a natural part of the Aqara Home app (iOS/Android) and its automations.  You can configure the IF conditions as well as THEN actions, and you will be able to use more notification or disarming options.

* Multi-Device Grouping feature is Aqara Home exclusive feature.

**85dB is the maximum decibel version of this product. Variants may exist to meet different country/region hardware requirements.

***An Aqara Zigbee 3.0 hub is required, to use the device with a particular Matter ecosystem, a Matter Controller of this ecosystem and a Matter-compatible Aqara hub are required.

Examples of Automation:

1. Fire Safety Alert

Enhances home safety by ensuring you are immediately notified in case of smoke detection.

IF Smoke Detector detects smoke, THEN activate all sirens in the house, turn on all lights to full brightness, and send a critical alert notification to your phone.

(Smoke Detector + Aqara Hub + LED Strip T1)

2. Disarm the Siren Easily

In case the detector was triggered, you will be able to check if there is any danger or disarm it easily. Unlike the traditional alarms, you can use both the Aqara Home app or other Aqara devices to do it.

IF the Smoke Detector is triggered AND Wireless Mini Switch is pressed, THEN turn off all sirens for Smoke Detector and Aqara Hub

(Smoke Detector + Aqara Hub + Wireless Mini Switch T1)

3. Integrating Automation Into Everyday Life

When the alarm is triggered, Aqara camera will monitor the triggering location and illuminates the escape route to provide safety assistance.

IF the Smoke Detector is triggered , THEN Turn the camera G3 to monitor the corresponding area and turn on the light on escape routes

(Smoke Detector + Aqara Hub + Aqara Camera + LED Strip T1)

4. Early Warning of Multiple Types of Dangerous

This all-in-one security alarm provides reliable protection for your home. Whether it’s a water leak, smoke detection or a door or window opened abnormally, you will be immediately alerted by alarm and notification, ensuring a quick response to any potential danger.

IF the Detector or Sensor is triggered, THEN activate all sirens in the house and send a critical alert notification to your phone

(Smoke Detector + Aqara HubAqara Water Leak Sensor T1 + Aqara Door and Window Sensor T1)

Frequently Asked Questions

Q

How does the Smoke Detector work?

A

The Smoke Detector uses the principle of smoke particles scattering the light. The higher the smoke concentration, the more obvious the light scattering, and the stronger the generated photocurrent, which will trigger the fire alarm.


Q

Can the Smoke Detector work alone?

A

Yes, it can only perform local sound and light alarms when it is not connected to the hub; It can realize functions such as remote alarm and smart automation when connected to the ZigBee hub.


Q

How to reset the Smoke Detector? When do I need to reset?

A
  1. Quickly press the mute/self-check button three times, and when you see the green light flashing three times, it indicates that the device has started to reset;
  2. If you want to connect the device to another hub, please reset the device.

Q

What are the possible reasons for the failure to add a Smoke Detector?

A
  1. Operation error, please add the device again according to the instructions in the manual or the app;
  2. The device is too far away from the hub, and it is recommended not to exceed 20 meters. Please try again after the device is moved closer to the hub;
  3. There are too many blocks between the device and the hub, and it is recommended that no more than two walls. Please try again after the device is close to the hub;
  4. The current hub does not support adding this device. For more supported hub models, please contact customer service.

Q

Why is the Smoke Detector offline?

A

Possible reasons:

  1. The accessory is too far away from the hub, please try to install the accessory closer to the hub.
  2. Low battery or dead battery. Please replace the battery.
  3. The accessory is installed on the metal surface and the signal is interfered. Please avoid metal surface.

Q

What should I know when installing the Smoke Detector?

A
  1. It is only intended for indoor installation and use.
  2. It is not suitable for installation in areas such as kitchens that are prone to non-fire smoke and steam.
  3. It is not suitable for installation in bathrooms and areas that are prone to moisture.
  4. Keep a distance of 1.5 m or more between the detector and ventilators, air conditioners, or vents.
  5. Keep a distance of 0.5 m or more between the detector and walls or beams.
  6. There should not be any obstructions within a horizontal distance of 0.5 m around the detector.
  7. It should be installed horizontally. However, if it is really necessary to install it at an angle, the angle of inclination should be no more than 45 degrees.
  8. Do not install the detector in environments with temperatures below -10°C or above 55°C.
  9. It is recommended to install the detector with screws.
  10. When using the adhesive sticker to install the detector, the installation surface must be cleaned in advance to ensure that the surface the adhesive sticker is attached to, is smooth, flat, dry, and clean.

Q

What may cause the Smoke Detector to trigger a false fire alarm?

A
  1. Cooking fumes or steam can trigger a false alarm.
  2. Humid weather that causes condensation can trigger a false alarm.
  3. The use of incense, electronic mosquito repellents, etc. can trigger a false alarm.
  4. Air freshener sprays or insecticides can trigger a false alarm.
  5. The accumulation of large amounts of dust on the inside of the detector can trigger a false alarm.

Q

How to silence the Smoke Detector after a false alarm?

A

Press the mute/self-check button on the surface of the device, Or enter the APP and click the “Mute” button on the homepage of the device to stop the alarm sound.


Q

How long will the alarm sound be stopped after the Smoke Detector is muted?

A
  1. When the sound is muted in the case of a fire alarm, the alarm sound will stop for about 80 seconds.
  2. When the sound is muted in case that the sensor is faulty or the battery is low, the alarm sound will stop for about 8 hours.

Q

What type of battery does the Smoke Detector use, and how long does it last?

A
  1. The detector uses a CR17450 lithium manganese battery.
  2. The battery can be used for about 10 years under normal circumstances; however, it may slightly differ depending on the environment the detector is used in.

Q

What do the flashing lights and beeps of the Smoke Detector mean?

A
  1. Low battery: The yellow light flashes once every 48s, and beeps once every 48 seconds;
  2. Failure: The yellow light flashes 3 times every 48s, and beeps 3 times every 48 seconds;
  3. Fire alarm: The red light flashes once every second, and beeps once every second, and there is a pause every three times;
  4. Associated alarm: The red light flashes once every 4 seconds, and beeps every 1 second, and there is a pause every three times;
  5. Normal monitoring: No lighting and no beeps.

Videos

Product Specifications

Physical and Performance Attributes

Weight260 grams
Dimensions (L x W x H)109 × 109 × 67 mm

Misc Product Attributes

Product Name Aqara Smoke Detector
Model SD-S01E, SD-S01D
Wireless Protocols Zigbee
Dimension ⌀104.6 × 42 mm
Battery DC 3V(CR17450)
Zigbee Operating Frequency 2405-2480 MHz
Zigbee maximum output power ≤ 13 dBm
Operating Temperature  0 °C ~ 40 °C
Operating Humidity 0 ~ 95% RH, no condensation
Implementation standards EN 14604:2005/AC:2008
What is in the Box Smoke Detector × 1, Mounting Plate × 1, Battery × 1, Accessory Kit × 1, User Manual × 1
